Product description, Technical parameters and configuration

Application fields

The element analysis for metal materials is a traditional work for the research and development, quality control, process control and other related works in the field of the metal smelting, casting and processing industry.

Skyray Optical Emission Spectrometer is widely used in the element analysis of ferrous and non-ferrous metal. The instrument can simultaneously analyze dozens of elements with a fast, accurate and stable performance, meeting the requirements in industrial development, process control, incoming inspection, product sorting, etc.

Skyray Optical Emission Spectrometer provides a convenient, eco-friendly and low-cost solution for metal analysis, making the R&D, production process and product quality more controllable, helping users upgrade the level of  technology and quality; while accelerating the relevant procedures and creating economic and environmental benefits for users. Optical Emission Spectrometer has been a typical device to evalue the level of technology and product quality for a factory.

Performance advantages

Based on the Multi-CCD detector and total spctrum technology, Optical Emission Spectrometer OES 6000 detect all the spectral lines within the range of wavelength; so it is extremely easy to install and add the matrix, channels and analytical program. With a compact size, it is easy to maintain and locate in the laboratory. OES 6000 is a convenient instrument for the analysis of  elements in non-ferrous metals.

Thanks to the Multi-CCD detector and total spctrum technology, it is easier to install and add the matrix, channels and analytical program in Skyray or customers’ laboratory

No vaccum design eliminate the pollution of oil from the vaccum pump

Work for 24/7 to serve your business with high stability and reliability

Fast way to analyze and demonstrate the results within 35 seconds

The operation and maintenance are simple and convenient for operators

All of the typical analytical programs are calibrated in Skyray, which are more accurate and test more types of metal grades

Easy to calibrate  the instrument with the standardization samples

Without chemical reagents, the analysis process is safe and eco-friendly.

Requirements

Ambient temperature: 15-30°C

Atmospheric humidity: ≤70%

Power: Voltage  220V ± 5V 50Hz; single phase with protective ground

No vibration, dust, strong electromagnetic interference, strong airflow or corrosive gases in the laboratory

Auxiliary equipments

Argon— The purity is above 99.999%

AC parameter voltage stabilized power supply— 1KVA

Grinding machine— For the samples like Steel, Nickel alloy, etc

Small lathe— For the samples like Aluminum, Copper, Zinc, Magnesium, etc

Air conditioner— Select suitable power according to the area of  laboratory

Technical Specifications

Spectrometer design

◇ Paschen-Runge polychromator

◇ Temperature controlled at 34±0.5℃, air type

◇ Special casting materials reduce the deformation of the chamber

Spark Source

◇ Digital plasma generator

◇ High energy pre-spark (HEPS)

◇ Frequency:100-1000Hz

◇ Current: 1-80A

Grating

◇ Holographic concave grating: 3600 l/mm

◇ Dispersion of the first order spectrum: 1.2nm/mm

◇ Effective wavelength range: 200-500 nm

Spark Stand

◇ 4mm analytical gap of the sample stand

◇ Jet stream technology

◇ No Argon consumption in standby mode

Detector

◇ High-performance linear array CCD

Dimension and Weight

◇ Dimensions: Height 300 Width 500 Depth 450

◇ Weight: 30 kg

Analysis Time

◇ Depend on the type of materials, typically less than 30 seconds

Electrical Power

◇ Max. 700VA

◇ Standby mode: 40VA

Technical advantages

No need of vacuum for the polychromator

Polychromator of OES 6000 is designed to work in the air environment, so the vacuum pump is eliminated. The polychromator is completely free from oil pollution of the vacuum pump. The purpose of more stable performance, more convenient maintenance and less power consumption are achieved with out vacuum pump.

Comprehensive analysis for the elements in most metals with the full spectrum detection

Based on the CCD detector with the full spectrum detection technology, the instrument can comprehensively detect the spectral lines of the most of the elements in the metal samples, and carry out analysis for  multi-matrix and multi-elements easily. Therefore, it is convenient and inexpensive to install and add the matrix, channels and analytical program in Skyray or customers’ laboratory.

Professional test solution

With long experience in analysis technology service, Skyray Instrument provides users with the sound solutions for the analysis of ferrous and non-ferrous metal.

The analysis programs in our solution are designed according to the classification of metal grade, meeting the various test demands of users perfectly.

The analysis programs are factory-calibrated with international or national standard samples, and have been fitted and corrected by professional software.

Just using a few pieces of the standardization samples supplied by Skyray, the user can carry out the routine calibration easily.  So it is unnecessary to purchase a large number of standard samples for the analysis program.

Top international suppliers provide the core components

Dispersive device—The grating manufactured by CARI ZEISS in Germany ensure the excellent resolution.

Detector—CCD manufactured by TOSHIBA in Japan ensure the detection of spectrum sensitive and low noise.

Optical lens is manufactured by CARI ZEISS in Germany;

Optical fiber is manufactured by Agilent Technologies in America.

Excellent thermostat system for the polychromator

The thermostatic chamber is configured with a feedback heating device and the highly efficient thermal insulating layer, ensuring the temperature of the polychromator.

The thermostatic chamber suppress the drift of optical path due to the slight changes in the dimensions of the mechanical components in different temperatures. Meanwhile, the constant temperature is beneficial to the  performance of photoelectric devices.

Test examples

Sampling

There are two kinds of sampling for spectrochemical analysis: the melt sampling and the product sampling. In the melt sampling, the metal liquid is injected into the mold and solidify into a solid sample. In the product sampling, the size and shape of the sample should be considered to judge whether cutting it or not.

Reference standards

ISO 14284 Steel and iron—Sampling and preparation of samples for the determination of chemical composition

ASTM E 1806 Standard Practice for Sampling Steel and Iron for Determination of Chemical Composition

ASTM E 716 Standard Practices for Sampling and Sample Preparation of Aluminum and Aluminum Alloys for Determination of Chemical Composition by Spectrochemical Analysis

Preparation

For the high hardness metal samples(such as steel, Nickel, Cobalt alloy), grind the surface with the grinding machine; for the low hardness metal samples( such as Aluminum, Copper, Zinc, Magnesium alloys),  turn the surface with  the lathe. The treated surface should be flat and smooth with scratches in the same direction.

Analysis

Place the sample on the spark stand and start the analysis process by operating the software. After completing the test, all the results of the customized elements are displayed simultaneously. The time of a single procedure is less than 40 seconds, and analyzing the same sample for the three times is  genegrally recommended .

Save the result

The results of the analysis could be stored in the database of the software or printed directly.
